High Temperature 1260C Fireproof Ceramic Fiber Board Thickness 25mm 50mm For Industrial Furnace
We offer quality control, full customization, design customization, and sample customization, holds product certifications for you all.
Leadsun ceramic fiber board is a high-quality lightweight refractory material, made from high-purity alumina silicate fibers, and is capable of withstanding continuous working temperatures up to 1430°C (2600°F).
This ceramic fiber board are refractory and insulation material, take ceramic fiber as the main raw materials, after fiber processing, slag removing, then add some binder, through vacuum forming process and drying process, to be made into high strength fiber board.
Furthermore, due to the extremely low thermal conductivity and negligible thermal capacity of the ceramic fiber board, this material can significantly reduce heat loss and enhance energy efficiency. Additionally, it can accelerate heating and cooling cycles, shorten processing time, and allow for quicker access to the equipment for inspection and maintenance after operation. Its durability, thermal stability, and ease of installation also contribute to extending service life, reducing downtime, and making it suitable for demanding thermal applications.
The ceramic fiber board is manufactured through advanced vacuum molding technology. It features a uniform and sturdy structure with excellent mechanical strength. Compared to traditional ceramic fiber blankets, it can better withstand high-speed airflows. This makes it an ideal inner lining solution for high-temperature industrial equipment such as furnaces, boilers, pipes and chimneys.
| Item |
Common |
Standard |
H Pure |
H Alumina |
Zirconium |
| AL2O3(%) |
44 |
46 |
47-50 |
52-55 |
39-40 |
| Fe2O3(%) |
1.2 |
1 |
0.2 |
0.2 |
0.2 |
| ZrO2(%) |
－ |
－ |
－ |
－ |
15-19 |
| Classification Temperature (℃) |
1100 |
1260 |
1260 |
1360 |
1430 |
| Working Temperature (℃) |
1000 |
1050 |
1100 |
1200 |
1350 |
| Density (kg/m3) |
260/320 |
260/320 |
260/320 |
260/320 |
260/320 |
| Permanent linear shrinkage(%)(after24 hours,density 128kg/m3) |
-4 |
-3 |
-3 |
-3 |
-3 |
| (1000°C) |
(1000°C) |
(1100°C) |
(1250°C) |
(1350°C) |
| Tensile strength (Mpa) density128kg/m3) |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
Advantages:
1. Low thermal conductivity,saves fuel
2. Ligh weight.replaces heavy back-up insulation.less steel required.
3. Excellent thermal shock resistance
4. Very low heat storage,faster heat and cool-down reducing cycle times
5. Resistant to hot gas erosion
6. Easy to cut, handle and install
7. Low sound transmission
8. Resists most chemical attacks
9. Resists penetration by molten aluminum and other non-ferrous metals
Applications
1. Hot face layer for high velocity or abrasive furnace atmosphere
2. Combustion chamber liners,boilers and heaters
3. Refractory lining for industrial furnaces in walls,roofs,doors,stacks,etc.
4. Transfer of molten aluminum and other non-ferrous metals
5. Expansion joint boards
6. Back-up insulation for brick and monolithic refractories
7. Barrier against flame or heat
